Polespring 50 AmbiDim

Category
Downlights, Polespring 50
Description

Our flagship Polespring 50 has been upgraded with an increased aperture which delivers market-leading performance. To minimise glare, the fitting comes with the 30° tilt and extra deep 25mm black baffle. New “clip-fit” mechanics create a modular design to create a more sustainable product. The standard white finish is now a textured matt RAL9003. The AmbiDim 50 engine offers a transition from a bright fresh 2700K to a warm ambient 1800K as it dims.

It is also available with the Pure 50 and Tune 50. For wet areas, see the separate Polespring 50 IP65 version.

Tested by Lighting Industry Association (LIA) Laboratory
Application
Accessories & variable optics allow for you to achieve tight focus to features, or for broader washes of light, reflecting off vertical surfaces.
Intelligent Design
Low glare downlight with elegant dim-to-warm solution.
Technical Specifications
Beam Beam Angle Source Engine Luminaire Power Supply CCT CRI IP Fire Rated Dimmable
Narrow 18° 1205 @ 2700K 1102 @2700K 837 @2700K 12 350mA 2700K to 1800K >93 Ra IP54 (Front)/IP20 (Rear) Yes DALI/Mains (Phase)/0-10V/Casambi/Non-Dim
Medium 26° 1205 @ 2700K 1101 @2700K 782 @2700K 12 350mA 2700K to 1800K >93 Ra IP54 (Front)/IP20 (Rear) Yes DALI/Mains (Phase)/0-10V/Casambi/Non-Dim
Wide 34° 1205 @ 2700K 1057 @2700K 684 @2700K 12 350mA 2700K to 1800K >93 Ra IP54 (Front)/IP20 (Rear) Yes DALI/Mains (Phase)/0-10V/Casambi/Non-Dim
SuperWide 51° 1205 @ 2700K 1095 @2700K 772 @2700K 12 350mA 2700K to 1800K >93 Ra IP54 (Front)/IP20 (Rear) Yes DALI/Mains (Phase)/0-10V/Casambi/Non-Dim
Drawings & Dimensions
Polespring 50 AmbiDim dimension image
Finishes
Accessories
Technical Download
Select your luminaire
ExpandCollapse Filters
Beam Angle
All
18°
26°
34°
51°
Beam
All
SuperWide
Narrow
Medium
Wide
Bezel Type
All
Rectangle
Round
Finish
All
White RAL 9003 Textured
KPS50XAM1827SW01
Downloads
+ Show- Hide Product Image
Polespring 50 AmbiDim product image
51°
SuperWide
Polespring AmbiDim 50 SuperWide 2700K – 1800K
KPS50XAM1827WI01
Downloads
+ Show- Hide Product Image
Polespring 50 AmbiDim product image
34°
Wide
Round
White RAL 9003 Textured
Polespring AmbiDim 50 Wide 2700K – 1800K
KPS50XAM1827NA01
Downloads
+ Show- Hide Product Image
Polespring 50 AmbiDim product image
18°
Narrow
White RAL 9003 Textured
Polespring AmbiDim 50 Narrow 2700K – 1800K
KPS50XAM1827ME01
Downloads
+ Show- Hide Product Image
Polespring 50 AmbiDim product image
26°
Medium
Rectangle
White RAL 9003 Textured
Polespring AmbiDim 50 Medium 2700K – 1800K
