Application
Use where a miniature, discreet, low glare, downlight is required as part of a layered lighting scheme in wet zones.
Waterspring 30
Category
Downlights
Finishes
Description
The Waterspring 30 IP54 LED miniature downlight is an ideal bathroom and outdoor downlight with an extra slim-line bezel with a deep black baffle to reduce glare. This IP rated LED downlight is also suitable for marine lighting.
Tested by Lighting Industry Association (LIA) Laboratory
Intelligent Design
Superior light output and quality whilst keeping glare to a minimum.
Technical Specifications
| Beam | Beam Angle | Source | Engine | Luminaire | Power | Supply | CCT | CRI | IP | Fire Rated | Dimmable |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Narrow | 11° | 172 | 156 | 146 | 2.2 | 350mA | 2700K | 98 Ra | IP65 (Front)/IP20 (Rear) | Yes | DALI/Phase cut/1-10V |
| Medium | 32° | 400 | 340 | 280 | 4.2 | 350mA | 2700K | >90 Ra | IP65 (Front)/IP20 (Rear) | Yes | DALI/Phase cut/1-10V |
| Wide | 46° | 400 | 320 | 240 | 4.2 | 350mA | 2700K | >90 Ra | IP65 (Front)/IP20 (Rear) | Yes | DALI/Phase cut/1-10V |
Drawings & Dimensions
Finishes
Black textured
White RAL 9003 Textured
Accessories
Technical Download
Select your luminaire
ExpandCollapse Filters
Beam Angle
All
11°
32°
46°
Beam
All
Narrow
Medium
Wide
Finish
All
Black RAL 9005
White RAL 9003 Textured
Waterspring 30 Black Medium 2700K
+ Show- Hide Product Image
32°
Medium
Black RAL 9005
Waterspring 30 Black Medium 2700K
Waterspring 30 White Wide 2700K
+ Show- Hide Product Image
46°
Wide
White RAL 9003 Textured
Waterspring 30 White Wide 2700K
Waterspring 30 Black Wide 2700K
+ Show- Hide Product Image
46°
Wide
Black RAL 9005
Waterspring 30 Black Wide 2700K
Waterspring 30 White Narrow 2700K
+ Show- Hide Product Image
11°
Narrow
White RAL 9003 Textured
Waterspring 30 White Narrow 2700K
Waterspring 30 Black Narrow 2700K
+ Show- Hide Product Image
11°
Narrow
Black RAL 9005
Waterspring 30 Black Narrow 2700K
Waterspring 30 White Medium 2700K
+ Show- Hide Product Image
32°
Medium
White RAL 9003 Textured
Waterspring 30 White Medium 2700K
